11 Technical data
11.1 General data
Table 16: Technical data
Attribute Value
Sensing distance 13 mm 25 mm
Sensing distance tolerance ±5 mm ±6 mm
Light spot size/light spot direction longitudinal:
3.8 mm x 0.9 mm
transverse:
0.9 mm x 3.8 mm
round:
0.9 mm²
longitudinal:
5.3 mm x 1.2 mm
transverse:
1.2 mm x 5.3 mm
Supply voltage
1
10.8 V – 28.8 V
Switching frequency 50 kHz
1-point teach-in (color mode): 16 kHz
Response time 10 µs
1-point teach-in (color mode): 30 µs
Jitter 5 µs
1-point teach-in (color mode): 15 µs
Switching type PNP or NPN or push/pull
Switching output (Q) PNP: HIGH = U
V
–3 V / LOW = 0 V
NPN: HIGH = U
V
/ LOW ≤ 3 V
Push/pull: HIGH = U
V
−3 V / LOW ≤ 3 V
Input, teach-in (ET) PNP and push/pull:
Teach: U = 10 V … < U
V
Run: U < 2 V
NPN:
Teach U < 2 V
Run: U = 10 V … < U
V
Input, blanking input (AT) – blanked/
free
PNP and push/pull:
Blanked: U = 10 V … < U
V
Free: U < 2 V
NPN:
Blanked: U < 2 V
Free: U = 10 V … < U
V
Input, light/dark (L/D) PNP and push/pull:
Light switching: U < 2 V
Dark switching: U = 10 V … < U
V
NPN:
Light switching: U = 10 V … < U
V
Dark switching: U < 2 V
Input, system sensitivity (F/C) PNP and push/pull:
Coarse: U = 10 V … < U
V
Fine: U < 2 V
NPN:
Coarse: U < 2 V
Fine: U = 10 V … < U
V
Enclosure rating IP 67
Ambient temperature (operation) –20 °C … +60 °C
Ambient temperature (UL) max. 60 °C
11 TECHNICAL DATA
46
O P E R A T I N G I N S T R U C T I O N S | KTS/KTX Prime 8020708.ZMT3/ | SICK
Subject to change without notice
