SICK MSM Series

Mounting Instructions
MSM
24
8 008 896.0799 © SICK AG • Germany • Safety Systems
Switch 1 2 3 4 Contact monitoring Restart inhibit A A A A yes yes A B A B no yes B A B A yes no *) B B B B no no *) *) In this case the restart inhibit must be a component of the KA control
MSLE xx-1xxxx
2
If the DIP switch setting is changed, the device model no longer corresponds to the device rating plate. Therefore any changes must be indicated on the device and in the machine documents.
ACHTUNG
