SICK S3000 PROFINET IO Mounting Instructions

4 Pin assignment
Figure 1: Terminals on the power supply plug
T
erminal assignment on the power supply plug
Terminal Signal Function Wire color for pre-assembled
po
wer supply plug with flying
leads
1 24V DC Supply voltage 1
2 – Reserved –
3 0V DC Supply voltage 2

A
M6 × 8
MOUNTING INSTRUCTIONS
8025886/ZC16/2022-10-24 | SICK M O U N T I N G I N S T R U C T I O N S | S3000 PROFINET IO, S3000 PROFINET IO-OF
7
Subject to change without notice
en
