Chapter 4 Technical Information
TiM55x/56x/57x ranging laser scanner
20 © SICK AG · Germany · All rights reserved · Subject to change without notice 8015883/YZK8/2016-07-07
Electrical installation
Important A longer connecting cable at the switching output of the TiM5xx should be avoided due to
the resultant voltage drop. This is calculated as follows:
2 x length x current
D V = -------------------------------------------------------------
Conductance value x cross section
Conductance value for copper: 56 m/W mm
2
.
Switching behavior PNP-switching against supply voltage V
S
.
SYNC/DEVICE READY:
Idle level: High (Device Ready),
Working level: Low (error), low pulse (15 Hz, index, corresponds to
measurement at 90°)
Properties – Short-circuit resistant and temperature-protected
– Not electrically isolated from the supply voltage V
S
Electrical values 0 V V
out
V
S
Guaranteed: (V
S
– 1.5 V)V
out
V
S
at I
out
100 mA
