Page #27 background imageLoading...
Page #27 background image
Technical Information Chapter 5
TiM55x/56x/57x
Measured value output
8015883/YZK8/2016-07-07 © SICK AG · Germany · All rights reserved · Subject to change without notice 27
Event information Defines whether the TiM5xx
outputs event information
unit_16 2 0 No event information
(can not be changed)
Event information
Type of event Fast digital input event string 4 FDIN
Encoder position Encoder position at the time
of the event.
Information in ticks
uint_32 4 00000000h ... FFFFFFFFh
Event time Time since the TiM5xx was
switched on up to the time of
the event in micro second
(μs)
uint_32 4 00000000h 0
FFFFFFFFFh 68,719,476,735
Angular position Angular position of the
TiM5xx at the time of the
event.
Information in 1/10,000
degree
int_32 4 –450,000 ... + 2,250,000
Telegram part Description Variable type Length (byte) Value range
(contd.)
