SICK TiM55 Series Mounting And Installation

Chapter 1 Technical Information
TiM55x/56x/57x ranging laser scanner
4 © SICK AG · Germany · All rights reserved · Subject to change without notice 8015883/YZK8/2016-07-07
About this document
Safety information
 Read the notes on mounting and electrical installation before carrying out these tasks.
 Read additionally the TiM5xx operating instructions to familiarize yourself with the
device and its functions.
 The TiM5xx complies with laser class 1, for laser warnings see the operating instruc-
tions.
 Only use the device in permissible ambient conditions (e.g. temperature, ground poten-
tial). Any applicable legal regulations or regulations of other authorities will have to be
observed during operation.
 Opening the screws of the TiM5xx housing will invalidate any warranty claims against
SICK AG.
 Repairs may only be performed on the TiM5xx by trained and authorized SICK AG ser-
vice personnel.
 The TiM5xx does not constitute personal protection equipment in sense of the respec-
tive applicable safety standards for machines.
 The TiM5xx must not come into contact with moisture and dust when the cover of the
USB port is open and/or the USB cable is connected. In this status, the TiM5xx does not
correspond to any specified IP protection class.
 For CE conformity, the maximum length of all connecting cables on the TiM5xx must not
exceed 3 m.
 Turn the swivel connector with the electrical connections max 180° from end position
to end position.
