SICK WTM4S - Page 307

0
150
(5.91)
100
(3.94)
50
(1.97)
200
(7.87)
250
(9.84)
300
(11.81)
0
y
x
y
x
Minimum distance in mm (y) between the set sensing
range and white background (90 % remission factor)
Example:
Safe suppression of the background
White background (90 %)
Black object (6 % remission factor)
Set sensing range x = 150 mm
Needed minimum distance to white
background y = 5.5 mm
Distance in mm (inch)
Recommended sensing range for
the best performance
20
(0.79)
16
(0.63)
12
(0.47)
8
(0.31)
4
(0.16)
1
6%/90%
90%/90%
3
2
18%/90%
插图 7: WTM4S-xxxxx8xx，MultiMode 1/3/4/5
3
1
2
0
150
(5.91)
100
(3.94)
50
(1.97)
200
(7.87)
250
(9.84)
300
(11.81)
Distance in mm (inch)
2204/10
4/10
4/10
240
250
D
C
A B
BluePilot
E
F
Recommended sensing range for
the best performance
插图 8: WTM4S-xxxxx8xx，MultiMode 1/3/4/5
1
黑色物体，6% 反射
2
灰色物体，18% 反射
3
白色物体，90% 反射
A
最小触发感应距离，单位：mm
B
最大触发感应距离，单位：mm
C
视野
D
设置背景抑制的范围切换阈值
E
触发感应距离显示
F
按转元件
蓝色
为实现最佳性能而建议的触发感应距离范围
MultiMode1+6：
操作指南
8028212/2023/10/20 | SICK 操 作 指 南 | WTM4S
307
如有更改，恕不另行通知
zh
