MultiMode 6
0
Distance in mm (inch)
Dimensions in mm (inch)
5
(0.20)
10
(0.39)
–10
(–0.39)
–5
(–0.20)
0
Recommended sensing range for
the best performance
300
(11.81)
200
(7.87)
100
(3.94)
400
(15.75)
500
(19.69)
600
(23.62)
500
(19.69)
110
(4.33)
10
(0.39)
Figure 18: WTB4SP-xxxxxAxx
MultiMode 2
0
Distance in mm (inch)
Dimensions in mm (inch)
5
(0.20)
10
(0.39)
–10
(–0.39)
–5
(–0.20)
0
Recommended sensing range for
the best performance
150
(5.91)
100
(3.94)
50
(1.97)
200
(7.87)
250
(9.84)
300
(11.81)
10
(0.39)
250
(9.84)
110
(4.33)
Figure 19: WTF4SD
11.4 Process data structure
WTM4S A00
IO-Link V1.1
Process data 2bytes
Byte 0: Bits 15 ... 8
Byte 1: Bits 7 ... 0
Bit 0/data type Q
L1
/Boolean
Bit 1/data type Q
L2
/Boolean
Bit 2 ... 15/description/data type Mode 1-6: Current Receiver Level [digits]
Mode 7: Distance value [0.1mm]
