3 The CNC Modules With USB
Connection
This manual describes the CNC modules 0460123A, 0480123A and 0480123D with
integrated USB↔ISA adapter. These CNC modules allow connecting a standard PC
and replace the CNC modules CNC 48.00
compact , CNC 48.00 compact VS and CNC
46.00.
3.1 Variants
The following table lists all available variants of the card 048010023. Contact
SIEB & MEYER for detailed information on the variants not described in this manual.
Variant Description Control
A USB↔ISA adapter ▶ CNC 46.00 (with integrated PC)
▶ CNC 48.00 compact (with integrated PC)
▶ CNC 48.00 compact VS (with integrated PC)
B
USB↔SM-NET
adapter
▶ CNC 48.00 (with IPC 50.01)
C USB↔SM-NET
adapter
▶ System 56.00 (external PC with SM-NET connection to the CNC
CNC 44.00 or CNC 48.00)
3.2 Scope of Supply
The following table lists the components delivered for the device.
Scope of Supply
Supply as retrofit
CNC 48.00 compact
SIEB & MEYER-
article number
0480123A
CNC 48.00 module consisting of:
▶ CPU logic card 048010012
▶ USB↔ISA adapter 048010023A
▶ front panel, handles and label "0480123A"
USB cable:
▶ USB standard 2.0
▶ integrated ferrite core
▶ length = 2 m
▶ 2 USB connectors: type A (rectangular) and type B
(square)
Supply as retrofit CNC 48.00
compact VS
SIEB & MEYER-
article number
0480123D
CNC 48.00 module consisting of:
▶ CPU logic card 048010022
▶ USB↔ISA adapter 048010023A
▶ front panel, handles and label "0480123D"
USB cable:
▶ USB standard 2.0
▶ integrated ferrite core
▶ length = 2 m
▶ 2 USB connectors: type A (rectangular) and type B
(square)
Supply as retrofit CNC 46.00 SIEB & MEYER-
article number
0460123A
CNC 46.00 module consisting of:
▶ CPU logic card 046010001
▶ USB↔ISA adapter 048010023A
▶ front panel, handles and label "0460123A"
USB cable:
▶ USB standard 2.0
▶ integrated ferrite core
W
The CNC Modules With USB Connection
0460123A/0480123A/0480123D - 17
3
