The CNC modules with USB connector are conceived for the following CNCs (name of
the CNC module with integrated USB USB↔ISA adapter in brackets):
▶ CNC 48.00
compact
(→ CNC module 0480123A)
▶ CNC 48.00
compact
VS (→ CNC module 0480123D)
▶ CNC 46.00 (→ CNC module 0460123A)
3.4 Connection Principle
The following figure shows the connection principle of aCNC module with USB connec‐
tion to a standard PC.
Fig. 1: Connection principle of a CNC module with installed USB↔ISA adapter
W
The CNC Modules With USB Connection
0460123A/0480123A/0480123D - 19
3
