5.1.1 Description of the LEDs

LED Color Status Description

L1 Green -12 V -12 V voltage supply available

L2 Green +12 V +12 voltage supply available

L3 Red CPU-FAIL CPU is not ready for operation

L4 Green +5 V +5 V voltage available

L5 — — — Without function

L6 Green CPU-RUN CPU runs

L7 Green USB-RUN

Data transmission via USB (480 Mbit/s)

Data transmission via USB (12 Mbit/s)

L8 Green PC-DATA Data transmission to external PC

L9 Green -- LAN connection to the CNC available

L10 Green -- Data transmission when LAN connection to the CNC is available

0460123A

24 0460123A/0480123A/0480123D -
