Page #4 background imageLoading...
Page #4 background image
Document No. 540-742
Installation Instructions
January 5, 2012
Information in this publication is based on current specifications. The company reserves the right to make changes in specifications and models
as design improvements are introduced. L
ONWORKS and LONMARK are trademarks of Echelon Corporation registered in the United States and
other countries. Other product or company names mentioned herein may be the trademarks of their respective owners.
© 2012 Siemens Industry, Inc.
Siemens Industry, Inc.
Building Technologies Divisin
1000 Deerfield Parkway
Buffalo Grove, IL 60089-4513
USA
Your feedback is important to us. If you have
comments about this document, please send them
to SBT_technical.editor.us.sbt@siemens.com
Document No. 540-742
Printed in the USA
Page 4 of 4
Accessories
Table 4. Room Sensor Pre-terminated Cables.
TEC Product Number
LTEC
Product
Number
Vinyl Plenum Plenum Only
Description
540-130 540-135 or
588-100A
588-100A 25-foot (7.6 m)
cable with
connections
540-131 540-136 or
588-100B
588-100B 50-foot (15.2 m)
cable with
connections
540-132 540-137 or
588-100C
588-100C 100-foot (30.5 m)
cable with
connections
NOTE:
LTEC cables can be used with either LTEC or
TEC sensors and controllers. However, LTEC
cables must be used with LTEC sensors and
controllers.
Review Table 5 to verify that you have the appropriate
mounting hardware. For retrofit installations, normally follow
the method used by the pre-existing device. You may need
to replace existing mounting hardware. Always mount the
sensor vertically.
Table 5. Mounting Accessories.
P/N Description Used For Reference
182-621 Gym Guard Kit, desert beige Gyms and similar environments requiring a guard. (Incompatible
with adapter bases and the extender ring.)
155-222P25 (TB 193)
182-621E Gym Guard Kit, satin chrome See Part Number 182-621. 155-222P25 (TB 193)
182-683 Metal (and Wood) Stud Mounting
Bracket (pkg. 5)
Single-sensor rough-in installations. Kit includes locator. 129-057
182-685 Spring Clips: Finished Drywall
Mounting Kit
(10 pack)
Drywall mounting. 129-073
192-506 Electrical Box Adapter Plate
Assembly Kit (pkg. 5)
Electrical boxes mounted flush with the wall and for gyms and
similar environments requiring a guard. (Also see Part Number
544-782.)
Figure 4
192-860 Finish Plate Kit 1 Gang 1 Sensor;
stainless steel
Single-sensor, low-cost mounting. Plate is 3.7 × 5.1 inches
(9.5 × 12.9 cm).
155-252P25 (TB 238)
536-666 Mounting Strap Standard light switch plate (field-supplied) to mount sensor on 2 × 4
electrical box.
540-040; 540-237
544-782* Single Adapter Base Mounting Kit 2 x 4 boxes, all single sensor installations on walls with oversized
holes, paint lines, etc., that need to be covered, and on exterior
brick/cement-type walls. Kit includes Electrical Box Adapter Plate
Assembly (Part Number 192-495. Adapter base is 3-1/2 × 5 inches
(8.8 × 12.7 cm).
Figure 4
544-783* Double Adapter Base Mounting Kit 4 × 6 boxes and all double sensor installations on walls with
oversized holes, paint lines, etc., that need to be covered, and on
exterior brick/cement-type walls. Kit includes two mounting plates
(Part Number 192-720). Adapter base is 5 × 7 inches
(12.7 × 18 cm).
Figure 4
544-784 Non-conduit Rough-in Kit, Double Double-sensor non-conduit rough-in installations. Kit includes
locator.
540-784
544-785* Extender Ring Kit Exterior brick or cement-type walls; fits to back of sensor base
plate.
544-800 Universal Adapter Kit Retrofitting a previous horizontal installation to a vertical one, or
when the screw spacing does not fit the electrical box adapter plate.
Kit includes multi-slotted adapter plate.
Figure 4
981-344 Electrical Box Cover Plate Kit 2 × 4 box rough-ins. Kit includes locator and connector.
Various finish plates Double-sensor, low-cost mounting for a variety of applications. 155-252P25 (TB 238)
* Product number suffixes indicate color: A = desert beige; B = white (For example, 544-782B)
