Transport, storage and packing
9229 9923 176 0B 7
2013-09-09
Opening the transport unit • Place the transport unit on a level, non-slip and pressure-resistant surface.
• Remove lifting gear or transport means.
• Remove plastic wrap.
• Lever out fasteners from the carton and lift off carton.
• Remove film from the vacuum circuit-breaker module.
• Check the delivery is complete.
• Check vacuum circuit-breaker module for damage.
• If the vacuum circuit-breaker module is damaged, ship it back in the transport
unit (see “Reusing the transport unit” on page 8).
Transporting with pallet,
without carton
The vacuum circuit-breaker module can be transported with the pallet, without the
carton.
• Thread carrying straps under the pallet or
• transport with fork lift.
Note
Do not use the vacuum circuit-breaker if parts are broken, i.e. if you find cracks,
flaking, bent metal parts, damaged plug-in contacts, tears or bare cables.
Send it back in its original transport unit (see “Reusing the transport unit”,
page 8).
Note
Carrying straps may scrape along the vacuum circuit-breaker module and dam-
age it.
If necessary, cover carrying straps with edge protection.
Fig. 3 Removing the film Fig. 4 Transporting with pallet possible
