4.4.5.6 Connecting Ethernet to the connection box
Note
Using an Ethernet data transmission rate of 100 Mbps
The Ethernet data transmission rate of 10 Mbps is not supported by 2nd generation Mobile
Panels.
Use a data transmission rate of 100 Mbps for communication with the Mobile Panel.
Maximum cable lengths
Ethernet cable Connection box used Maximum cable length in‐
cluding connecting cable
Between Mobile Panel and con‐
nection box
• Connection box standard
• Connection box advanced
25 m
Between Mobile Panel and PRO‐
FINET/PROFIsafe station
• Connection box standard
• Connection box advanced
125 m
Requirement
• The connection box is mounted.
• The connection box is open.
• 1 Ethernet cable (not preassembled)
• 1 screwdriver, PZ 2
• 1 stripping tool
Connecting
4.4 SIMATIC connection box
Handheld Terminal HT 10
50 Equipment Manual, 09/2020, A5E47430965B AA
