Siemens 6SE7031-7EE85-1AA0 - Page 178

Parameter List 09.02
5-20 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
PNU
* : Conf.
Par.
OP1S parameter name
Description
Value range
[phys. unit]
Selection text
Display
Indices
Factory-
setting
See
Modify
(access /
status)
P569
*
Src Jog2 ON
Source of the 'Jog 2' command (control word 1, bit 9)
Description see P568
B/R parameter
PNU=239Hex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
0
2/ BR
2/ BR
P571
*
Src Reduce DC V
Source for the "Reduce U
d
" control command (control word 1, bit 11)
Wait for U
d
reduction
0: U
d
reduction inactive
1: U
d
reduction requested (permanent U
d
reduction)
other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=23BHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
0
2/ ABR
2/ ABR
P572
*
**
Src RegenRelease
Source for the "Regenerating enable" control command (control word 1, bit
12)
0: Regenerating inhibited
1: Regenerating enabled
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=23CHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
(1)
2/ BR
2/ BR
P573
*
Src No ExtFault3
Source for the "External fault 3" control command (control word 1, bit 13)
L signal causes disconnection of the faulted drive.
0: Not allowed
1: No external fault 3
1003: Binary input 3 of the CUR board
Other values: see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
B/R parameter
PNU=23DHex; Type=L2; Scaling: 1Hex
=
∧
1
1 to 6005 2
1
2/ BR
2/ BR
P574
*
Src Motor/Regen
Source for the "Generating/motoring" control command (control word 1, bit
14)
0: Control command ineffective (motoring and
generating mode
permitted
1: Not allowed
Other values:
see allowed settings in Section 4.3.1.1 (process data
wiring of the control word)
During circuit identification parameter value 0 must be set.
If a rectifier unit is present, this parameter is visible with effect from software
version * 4.4.
B/R parameter
PNU=23EHex; Type=L2; Scaling: 1Hex
=
∧
1
0 to 6005 2
0
2/ BR
2/ BR
