Options 09.02
9-2 Siemens AG 6SE7087-6AK85-1AA0
Rectifier/Regenerating Unit Operating Instructions
Codes:
The last figure in the order code identifies the module location or slot of the electronic box (see below):
1 . . . Board location 2
2 . . . Board location 3
4 . . . Slot D
5 . . . Slot E
6 . . . Slot F
7 . . . Slot G
The following additional modules can be supplied under two order numbers
• under the order number of the board without accessories (such as connectors and Short Guide)
• as a retrofit kit: Board with connectors and Short Guide
Board Order number of board (w/o accessories) Order number of retrofit kit
ADB 6SE7090-0XX84-0KA0 6SE7010-0KA00
CBC 6SE7090-0XX84-0FG0 6SE7010-0FG00
CBP2 6SE7090-0XX84-0FF5 6SE7010-0FF05
Slots in the electronics box Boards
Left Slot 1 (CUR) CUR
Center Slot 3 (options) SCB1 / SCB2 / CBC (with ADB) / CBP2 (with ADB)
Right Slots 2 (options) CBC (with ADB) / CBP2 (with ADB) / SCB1 / SCB2 / T100 /
T300 / T400
NOTE
Only one of each option board type may inserted in the electronics box.
TB (technology boards, e.g. T400) must always be inserted at slot 2.
If only one option board is used it must always be inserted at slot 2.
Small format modules (CBP and CBC) must be plugged in on the adapter board on the right or below (in Slot
E or if a technology module is also used in Slot G).
Use of Slots D and F on adapter boards is not possible because the module plugged in there is not detected
by the basic device.
Table 9.2 Slots in the electronics box
Local bus adapter (LBA) for mounting optional supplementary boards
Optional supplementary boards can be installed only in conjunction with the LBA option. If an LBA is not already
fitted in the SIMOVERT 6SE70, one must be installed in the electronics box to accommodate the optional
board.
