Siemens 6SL3352-7AE32-1AA1 Parameter Guide

Block Diagram and Terminals Issue 01/06
MICROMASTER 440 Parameter List
10 6SE6400-5BB00-0BP0
Cable opening for
mains conection
U1/L1, V1/L2, W1/L3
Shield connection
Mains cable PE
Hoisting eyes
C
able opening DCPA, DCNA
for connection of an
external braking unit
Mains cable
Phase U1/L1, V1/L2, W1/L3
Top adjustment rail
Bottom adjustment rail
Status Display Panel
Shield connection
control leads
Transformer adaption
Motor cable
Phase U2, V2, W2
Motor cable
PE Shield connection
Fan screws
Bottom retaining screw
Elektronic box
Top retaining screw
Connection to
Y-Capacitor
Connection DCPA, DCNA
for external braking unit
Fan fuses
Fan
Connection for dv/dt filter
DCPS, DCNS
Fig. 1-3 Frame Size GX
www . ElectricalPartManuals . com

Siemens 6SL3352-7AE32-1AA1 Specifications

General

Brand	Siemens
Model	6SL3352-7AE32-1AA1
Category	Inverter Drive
Language	English
