Nameplate with approval information
The nameplate with approval information is located on the front of the enclosure.
D
E
F
,,*([LD,,&777*D*E
H
G
1a Characteristics of the hazardous area
1b Type of protection
1c Group (gas, dust)
1d Maximum surface temperature (temperature class)
1e Device protection level
Figure 2-2 Example
Measuring point label
The measuring point label is fastened with a wire under the front cover.
.... to .... mbar
Long tag (TAG)
Measuring point description
Y01 (max. 5 characters)
Y16 (max. 32 characters)
max. 10 characters
Y99: 1234
<PD[FKDUDFWHUV
Figure 2-3 Example
Introduction
2.6 Nameplate layout
SITRANS P320/P420 with 4 to 20 mA/HART
14 Compact Operating Instructions, 09/2018, A5E38874562-AB
