8.1.3 Gauge pressure from the differential pressure series
Gauge pressure input from the differential pressure series
Measured variable Gauge pressure and differential pressure
Measuring span (continuous‐
ly adjustable) and maximum
operating pressure (accord‐
ing to 2014/68/EU Pressure
Equipment Directive)
Measuring span Maximum permissible
operating pressure
MAWP (PS)
Max. permissible
test pressure
1 ... 20 mbar
0.1 ... 2 kPa
0.4015 … 8.031 inH
2
O
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
1 ... 60 mbar
0.1 ... 6 kPa
0.4015 … 24.09 inH
2
O
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
2.5 ... 250 mbar
0.2 ... 25 kPa
1.004 … 100.4 inH
2
O
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
6 ... 600 mbar
0.6 ... 60 kPa
2.409 … 240.9 inH
2
O
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
16 ... 1600 mbar
1.6 ... 160 kPa
6.424 … 642.4 inH
2
O
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
50 ... 5000 mbar
5 ... 500 kPa
20.08 … 2008 inH
2
O
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
0.3 … 30 bar
0.03 ... 3 MPa
4.35 … 435 psi
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
5 … 100 bar
0.5 ... 10 MPa
76.9 … 1450 psi
160 bar
16 MPa
2320 psi
240 bar
24 MPa
3480 psi
Gauge pressure measuring limits from differential pressure
series
Lower measuring limit
● Measuring cell with silicone oil filling
30 mbar a/3 kPa a/0.44 psi a
● Measuring cell with inert oil
30 mbar a/3 kPa a/0.44 psi a
● Measuring cell with FDA-compliant oil
100 mbar a/10 kPa a/1.45 psi a
Upper measuring limit 100% of max. range (for oxygen measurement: max. 100 bar/
10 MPa/1450 psi and 60 °C ambient temperature/medium
temperature)
Start of scale value Between the measuring limits (continuously adjustable)
Technical data
8.1 Input
SITRANS P320/P420 with 4 to 20 mA/HART
Compact Operating Instructions, 09/2018, A5E38874562-AB 63
