Operating conditions according to KTA
3503
Gauge pressure series
2)
Aluminum and stainless steel enclosure
Differential pressure series
2)
Aluminum and stainless steel enclosure
Vibrations (sine)
IEC 60068-2-6
9 ... 35 Hz at 10 m/s²
1 octave/min
1 cycle/axis
Vibrations (sine)
IEC 60068-2-6
5 ... 7 Hz at 20 mm
9 ... 100 Hz at 20 m/s²
10 octave/min
1 cycle/axis
Continuous shocks (half-sine)
IEC 60068-2-27
300 m/s²
11 ms
6 shocks/axis
2) With mounting bracket
Operating conditions according to IEC
61298-3 (2g normal)
Gauge pressure series
2)
Aluminum and stainless steel enclosure
Differential pressure series
1)2)
Aluminum and stainless steel enclosure
Vibrations (sine)
IEC 60068-2-6
10 ... 58 Hz at 0.3 mm
58 ... 1000 Hz at 20 m/s²
1 octave/min
20 cycles/axis
1) Without mounting bracket
2) With mounting bracket
Operating conditions according to IEC
61298-3 (5g enhanced)
Differential pressure series
1)
Aluminum and stainless steel enclosure
Vibrations (sine)
IEC 60068-2-6
10 ... 58 Hz at 0.7 mm
58 ... 1000 Hz at 50 m/s²
1 octave/min
20 cycles/axis
1) Without mounting bracket
Technical data
8.5 Vibration resistance
SITRANS P320/P420 with 4 to 20 mA/HART
94 Compact Operating Instructions, 09/2018, A5E38874562-AB
