Dimensioned drawings up to hardware version /CC
Figure 14 Dimensions of the FO-Repeater up to hardware version /CC
Dimensions in mm
1
) Minimum length of standard mounting rail
2
) Dimensional drawing applies to standard mounting rail acc. to IEC / EN 60715; 35 × 7.5
Crosstip screw
Deblocking
Wall-mounted standard mounting rail not included in the scope of delivery
L ≥ 188
1)
188
120
11
70.8
14.5
2)
