7XV5461-0Bx00 English
C53000-B1174-C173-5 73
Dimensioned drawings from hardware version /DD
Figure 15 Dimensions of the FO-Repeater from hardware version /DD
120
13.5
69.8
14.5
2
)
Note: Please note that there are minor differences in the dimensions of devices
from the hardware version /DD as compared with devices up to the hardware
version /CC.
2
) Dimensional drawing applies to standard mounting rail acc. to IEC / EN 60715; 35 × 7.5
1
) Minimum length of standard mounting rail
Dimensions in mm
Deblocking
Crosstip screw
Wall-mounted standard mounting rail not included in the scope of delivery
Error of Link Down / Echo Mode
Port 1 Data
Port 2 Data
Power On
Reset:
>1 sec
Echo Mode <1 sec
Normal Mode
Port 3 Port 2
Port 1
Port 2 Port 1
Echo Mode
Rx Tx
Rx Tx
L 188
1
)
188
Port 3
Tx Rx
Port 2
Rx Tx
Port 1
Rx Tx
GOK
115-250VAC / 24-250VDC
