Order Information for 9330 /9350 Series Meters
Catalog Number
Description
9 3 X X D C
1 0 0
–
–
0 Z Z Z Z A
NOTE 1 – The listed modems are not suitable for European applications. Contact Siemens for special versions.
Meter base unit and display options
• Meter with integrated display D
• Meter with remote display (includes 6’ cable) R
• Meter without display (Tran version) T
• Meter with integrated display installed in S1 retro-fit switchboard kit (meter in cage with cover, no casing) S
• Meter with integrated display installed in FT21 retro-fit switchboard kit (meter in cage with cover, no casing)
F
Communications
• RS485 with ION / Modbus RTU / DNP - Factory configured for ION C
• RS485 with ION / Modbus RTU / DNP - Factory configured for Modbus
(Available for Tran version only)
M
Power Supply
• 85-240 Vac / Vdc 1
• 20-60 Vdc 2
Input Voltage
• 50-347 Vac 0
Frequency
• 50-60 Hz 0
Modem ONLY AVAILABLE WITH 9330 AND 9350 MODELS
• None 0
• Modem w/ RJ-11
(See Note 1 below)
1
• Modem w/ plug connector
(See Note 1 below)
2
Ethernet Network Card or Analog I/O (Note: Analog options not available with Ethernet or TRAN options)
• None Z
• Yes (Enables Web Meter Functionality) N
• 4 Analog Inputs 0 to 1 mA B
• 4 Analog Inputs 0 to 20 mA C
• 4 Analog Outputs 0 to 1 mA D
• 4 Analog Outputs 0 to 20 mA E
• 4 Analog Inputs 0 to 1 mA 4 Analog Outputs 0 to 1 mA F
• 4 Analog Inputs 0 to 20 mA 4 Analog Outputs 0 to 20 mA G
Captured Wire Connector for input voltage and current connections
• None (std. screw terminals) Z
• Yes P
DIN rail Mounting (for Remote and Tran only – selections “R” and “T” above)
• None Z
• Yes D
Tropicalization Option
• None Z
• Yes T
Specials
• None A
9330/9350 Advanced Power Meters
