Siemens LV 10 · 2004
7/16
SENTRIC Switch Disconnectors
Accessories
SENTRIC K Switch Disconnectors from 63 A to 1000 A
7
■ Selection and ordering data
4) For further 3SB14 00–0 switching elements with other contact types, see
“Pushbuttons and Indicator Lights".
DT 3KA50 30/
3KA51 30
PS* Weight
per PU
approx.
DT
3KA50 40/
3KA51 40/
3KA52/
3KA53
PS* Weight
per PU
approx.
Order No. kg Order No. kg
3KA52
3KX3 552–3DA01
Terminal cover }
3KX3 552–3DA01 1 set 0.077 } 3KX3 552–3DA01 1 set 0.077
(1 set = 6 units)
for 3-pole devices
3KA53
} 3KX3 553–3DA01 1 set 0.147
3KA52
(1 set = 8 units)
for 4-pole devices
B 3KX3 552–3DB01 1 set 0.102 B 3KX3 552–3DB01 1 set 0.102
3KA53
B 3KX3 553–3DB01 1 set 0.170
8UC62 12–1BB20
Door-coupling rotary operating
mechanism IP65
black handle, shaft 300 mm
}
8UC61 11–1BB10 1 unit 0.347 } 8UC62 12–1BB20 1 unit 0.404
Door-coupling rotary operating
mechanism IP65
EMERGENCY-STOP (yellow/red),
shaft 300 mm
}
8UC61 21–3BB10 1 unit 0.353 } 8UC62 22–3BB20 1 unit 0.426
Operating mechanism for fixed
mounting
black handle, shaft 250 mm
}
3KX3 516–1AA 1 unit 0.088 } 3KX3 536–1AA 1 unit 0.155
3KX3 516-1AA
Extension shaft 300 mm long B
8UC60 31 1 unit 0.068 B 8UC60 32 1 unit 0.132
Extension shaft 600 mm long B
8UC60 81 1 unit 0.136 B 8UC60 82 1 unit 0.265
Shaft connection piece B
8UC60 21 1 unit 0.031 B 8UC60 22 1 unit 0.023
Auxiliary switches
1 NO + 1 NC
1)
A 3SB14 00–0A 1 unit 0.019 A 3SB14 00–0A 1 unit 0.019
20 ms leading
1 NO + 1 NC – B 3KX3 552–3EA01 1 unit 0.019
DT 3KA55/
3KA57/
3KA58
PS* Weight
per PU
approx.
Order No. kg
Terminal cover } 3KX3 557–3DA01 1 set 0.277
(1 set = 6 units)
for 3-pole devices
(1 set = 8 units)
for 4-pole devices
B 3KX3 557–3DB01 1 set 0.362
3KX3 176-1E
Door-coupling rotary operating
mechanism IP65
black handle, shaft 300 mm
}
8UC63 13–1BB30 1 unit 0.973
Door-coupling rotary operating
mechanism IP65
EMERGENCY-STOP (yellow/red),
shaft 300 mm
}
8UC63 23–3BB30 1 unit 0.999
Operating mechanism for fixed
mounting
black handle, shaft 250 mm
}
3KX3 176–1E 1 unit 0.285
Extension shaft 300 mm long C 8UC60 33 1 unit 0.217
Extension shaft 600 mm long B 8UC60 83 1 unit 0.430
Shaft connection piece B 8UC60 23 1 unit 0.085
Auxiliary switch 1 NO + 1 NC
1)
A 3SB14 00–0A 1 unit 0.019
* This quantity or a multiple thereof can be ordered.
