Siemens Actuators SAS.., SAT.. for valves CE1P4041en
Smart Infrastructure Connection diagrams and dimensions 2019-04-09
Stroke actuators SA.. without manual adjuster
Typ A
[mm]
B
[mm]
C
[mm]
C1
[mm]
C2
[mm]
D
[mm]
E
[mm]
F
[Zoll] [mm] [mm]
[kg]
1 2
SAS..
137.6
1)
151
2)
80 106.5 21.9 84.6
29.9 21.8 G ¾ 100 200
0.68
M16
3)
M20
3)
Mit ASK39.2: 155 126 248 99 149 0.83
1)
Black cover
2)
Blue manual adjuster
3)
Thread length max. 9 mm
