Siemens Acvatix SAX61 MO Series - Technical Data; Power Supply and Consumption

73 / 87
Siemens Actuators SAX.., SAY.., SAV.., SAL.. for valves CE1P4040en
Smart Infrastructure Technical data 2020-01-30
5 Technical data
SAY.. SAX.. SAV.. SAL..
Power
supply
Operating voltage
SA..31.. AC 230 V ± 15 %
SA..61.. AC 24 V ± 20 % / DC 24 V + 20 % / -15 % (SELV)
SA..81.. AC 24 V ± 20 % / DC 24 V + 20 % / -15 % (SELV)
Frequenz 45…65Hz
External supply line protection (EU)
· 6 A...10 A slow
· Circuit breaker max. 13 A
Characteristic B, C, D according to EN 60898
· Power source with current limitation of max. 10 A
Power consumption at 50 Hz
SAX31.00 Stem retracts / extends 3.5 VA / 2 W
- -
SAX31.03 Stem retracts / extends 6 VA / 3.5 W
SAX61.03.. Stem retracts / extends 8 VA / 3.75 W
Holding state 3.5 VA / 1.5 W
SAX61.03/MO Stem retracts / extends 8,7 VA / 4,25 W
SAX81.00.. Stem retracts / extends 3.5 VA / 2.25 W
SAX81.03.. Stem retracts / extends 5 VA / 3.75 W
SAX31P03 Stem retracts / extends
-
6.5 VA / 4 W
- -
SAX61P03 Stem retracts / extends 9.5 VA / 4.5 W
SAX61P03/MO Stem retracts / extends 10.2 VA / 5 W
SAX81P03 Stem retracts / extends 7 VA / 4.5 W
SAV31.00.. Stem retracts / extends
-
6.5 VA / 4 W
-
SAV61.00.. Stem retracts / extends 9.5 VA / 4.5 W
SAV61.00/MO Stem retracts / extends 10,5 VA / 5 W
SAV61P00/MO Stem retracts / extends 10,2 VA / 5 W
SAV81.00.. Stem retracts / extends 7 VA / 4.5 W
SAL31.00T10 Rotary actuator turns
- -
3.5 VA / 2 W
SAL31.00T20 Rotary actuator turns 4.5 VA / 2.75 W
SAL31.00T40 Rotary actuator turns 7 VA / 4 W
SAL31.03T10 Rotary actuator turns 5.5 VA / 3.25 W
SAL61.00T10 Rotary actuator turns
Holding state
5 VA / 2.5 W
3.5 VA / 1.5 W
SAL61.00T20 Rotary actuator turns
Holding state
6 VA / 2.75 W
3.5 VA / 1.5 W
SAL61.00T40 Rotary actuator turns
Holding state
9 VA / 4 W
3.5 VA / 1.5 W
SAL61.03T10 Rotary actuator turns
Holding state
7.5 VA / 3.5 W
3.5 VA / 1.5 W
SAL81.00T10 Rotary actuator turns 3 VA / 2 W
SAL81.00T20 Rotary actuator turns 4 VA / 2.75 W
SAL81.00T40 Rotary actuator turns 6 VA / 3.75 W
SAL81.03T10 Rotary actuator turns 5 VA / 3.5 W
SAY31P03 Stem retracts / extends 6 VA / 3.5 W
- - -
SAY61P03 Stem retracts / extends 8 VA / 3.75 W
Holding state 3.5 VA / 1.5 W
SAY61.03U Stem retracts / extends 8 VA / 3.75 W
Holding state 3.5 VA / 1.5 W
SAY61P03/MO Stem retracts / extends 8.7 VA / 4.25 W
SAY81P03 Stem retracts / extends 5 VA / 3.75 W
SAY81.03U Stem retracts / extends 5 VA / 3.75 W
Switch-on current 3-position actuators
(typical)
1)
SA..31.. 2.3 A 2.3 A 2.3 A 2.3 A
SA..81.. 4.5 A 4.5 A 4.5 A 4.5 A
