Siemens ACVATIX SAYxP Series Basic Documentation

13 / 92
Siemens Actuators SAX.., SAY.., SAV.., SAL.. for valves CE1P4040en
Building Technologies Engineering 2018-12-05
ASK31N 4 pcs. M6 x 16 mm
1 pc. M5 x 20 mm incl.
nut
1 pc. 12 mm
1 pc. 12 mm
ASK32N 4 pcs. M6 x 16 mm
1 pc. M5 x 20 mm incl.
nut
1 pc. 12mm
ASK33N 4 pcs. M6 x 16 mm
1 pc. M5 x 20 mm incl.
nut
1 pc. 12 mm
1 pc. 12 mm
ASK35N 2 pcs. M8 x 50 mm
1 pc. M5 x 20 mm incl.
nut
1 pc. 12 mm
1 pc. 16 mm
4040U19
12 mm
16 mm
