Siemens ACVATIX SAYxP Series Basic Documentation

17 / 92
Siemens Actuators SAX.., SAY.., SAV.., SAL.. for valves CE1P4040en
Building Technologies Engineering 2018-12-05
Stroke 20 mm 40°mm
Typical applications Stroke actuators Data
Sheet
Positioning force
800 N 1600 N
· Heating plants
· Ventilation and air conditioning
plants
· Heat generation
· Heat distribution
· District heating plants
SAX..
SAV..
5)
N4501
N4503
SAX.. SAV..
Valves Basic Doc. (P4030)
Δp
s
[kPa]
Δp
max
[kPa]
Δp
s
[kPa]
Δp
max
[kPa]
Valves Data Sheet Valve type DN k
vs
[m
3
/h]
PN16 N4403 VVF42.15-..
2)
15 1,6 / 2,5 / 4
1600
400
- -
VVF42.20-6.3 20 6,3
VVF42.25-..
2)
25 6,3 / 10
VVF42.32-16 32 16 900
VVF42.40-..
2)
40 16 /25 550 1250
400
VVF42.50-..
2)
50 31,5 / 40 350 300 750
VVF42.65-..
2)
65 50 / 63 200 150 450
VVF42.80-..
2)
80 80 / 100 125 75 250
VVF42.100-..
2)
100 125 / 160
- -
160 225
VVF42.125-..
2)
125 200 / 250 125 125
-10…130 °C
3)
VVF42.150-..
2)
150 315 / 400 80 80
PN16 N4403 VVF42.50-40K 50 40
1600 400 - -VVF42.65-63K 65 63
VVF42.80-100K 80 100
VVF42.100-160K 100 160
- -
1600
400VVF42.125-250K 125 250
-10…130 °C
3)
VVF42.150-360K 150 360 1400
PN16 N4404 VVF43.65-..
2)
65 50 / 63
- -
450 400
VVF43.80-..
2)
80 80 / 100 250 225
VVF43.100-..
2)
100 125 / 160 160 125
VVF43.125-..
2)
125 200 / 250 125 90
20…130 °C
3)
VVF43.150-..
2)
150 315 / 400 80 60
PN25 N4373
VVF52.15-..
2) 4)
15
0.16 / 0.2 / 0.25 /
0.32 / 0.4 / 0.5 0.63
/ 0.8 / 1 / 1.25 / 1.6 /
2 / 2.5 / 3.2 / 4
2500 1600
- -
VVF52.25-..
2)
4)
25 5 / 6.3 / 8 / 10 1500 1200
-20…130 °C
3)
VVF52.40-..
2)
4)
40 12.5 / 16 / 20 / 25 500 400
PN25/16 N4405
VVF53.15-..
2)
15
0.16 / 0,2 / 0.25 /
0.32 / 0,4 / 0.5 /
0.63 / 0,8 / 1 / 1.25 /
1.6 / 2 / 2.5 / 3.2 / 4
2500
1200
- -
VVF53.20-6.3 20 6.3
VVF53.25-..
2)
25 5 / 6.3 / 8 / 10 1600
VVF53.32-16 32 16 900 750
VVF53.40-..
2)
40 12.5 / 16 / 20 / 25 550 500 1250 1150
VVF53.50-..
2)
50 31.5 / 40 350 300 750 700
PN25 VVF53.65-63
)
65 63
- -
450 400
VVF53.80-100
)
80 100 250 225
VVF53.100-160 100 160 160 125
VVF53.125-250 125 250 125 90
-20…130 °C
3)
VVF53.150-360 150 360 80 60
PN16 N4363 VVG41.11...12
1)
15 0.63 / 1
1600
800
- -
VVG41.13 15 1.6
VVG41.14 15 2.5
VVG41.15 15 4
VVG41.20 20 6.3
VVG41.25 25 10 1550
VVG41.32 32 16 875
VVG41.40 40 25 525 525
-25…130 °C
3)
VVG41.50 50 40 300 300
1)
insert running number instead of k
vs
value
2)
.. = insert k
vs
value
3)
For media temperatures > 130 °C use electrohydraulic actuators SKD.. (N4561), SKB.. (N4564).
4)
valves no longer in the active sale
5)
SAV..: This product line of actuators might not be available in all countries. Please talk to your local
contact or consult your local internet pages of www.buildingtechnologies.siemens.com
