Cable specifications
14
Siemens AB
Security Products 05.2015
8 Cable specifications
The table provides a guideline for selecting an appropriate cable type only.
Other cable types are also compatible with the system and can be used to achieve the same results.
Communi-
cation Type
Recommended Cable Specifications
Cores Pairs AWG Cores J-Y(St)Y
Diameter
(mm)
Wire Type Insulation Shield Jacket
RS-485
4 2
28
7 x 36 0.6
Tinned
Copper
Foam
Polyethylene
Aluminium foil - Polyester
tape / braided shield
PVC
6 3
8 4
RS-232
4 2
24
7 x 32 0.6
Tinned
Copper
Foam
Polyethylene
Aluminium foil - Polyester
tape / no braid
PVC
6 3
8 4
RS-422
4 2
24
7 x 32 0.6
Tinned
Copper
Foam
Polyethylene
Aluminium foil - Polyester
tape / no braid
PVC
6 3
8 4
RJ-45
8 4 24
Solid 0.6 Bare
Copper
Polyethylene Unshielded
PVC
8 4 24
7 x 32 0.6 Tinned
Copper
RJ-12
8 4 24
Solid 0.6 Bare
Copper
Polyethylene
Aluminium foil - Polyester
tape / no braid
PVC
8 4 24
7 x 32 0.6 Tinned
Copper
Power (12/24
V DC)
2 1 18
19 x 30 1.0 Tinned
Copper
Foam
Polyethylene
Unshielded PVC
9 Programming and firmware download
The ADE5300 is programmed using SiPass software, via the AC5100, or using the
„FLN Configurator“ application. Please refer to the appropriate User’s Manual for
more Information.
