7 Connections and LEDs
7.1 Connections
It is recommended that you wear a grounding strap while carrying out this procedure.
1. Connect each Wiegand reader to the appropriate READER port of the
ADE5300, or connect the SIEMENS RS485 readers to the SRB RS485 port.
Up to 8 Siemens RS485 readers can be daisy chained (from one reader to
another) on the same connection.
Each reader must be wired correctly. For more information, see Section 7.3: Reader wiring.
The total resistance for each reader cable must not exceed 16.8 Ohms.
2. Connect the Request to Exit (REX) switch (e.g. door opener button) to the
appropriate REX input on the ADE5300.
3. Connect each door contact (door monitor) to the appropriate D/C input port
on the ADE5300. For example, connect the contact for Door 1 to “D/C1”.
4. Connect auxiliary inputs (if required) to the Input IN1 to IN16 on the PCB.
Listed end-of-line resistors must be connected to the wiring for each input device if they are to be
supervised. For more information, see Section 7.4: Wiring of monitored input.
Please note (this applies to all inputs): The total cable run resistance must not exceed 100 Ohms.
5. Connect any auxiliary output devices to the AUX OUT ports (open collector)
on the ADE5300.
6. Connect each door opener to the appropriate RELAY OUT port on the
ADE5300. Access doors can only be connected to output relays that are
controlled by readers.
7. For example, connect the lock for door 1 to the “RELAY1 OUT” connection on
the ADE5300. Ensure that the power supply used to drive the lock is
sufficiently rated.
8. Connect the wiring from the fire or emergency override system to the FOR
IN ports, if required. Ensure the correct FOR link settings are applied.
9. Connect the next device in the Fire Override sequence to the FOR OUT ports
(only if required).
10. Connect the FLN wires (from the AC5100) to the FLN RS485 port.
11. Connect the active (+ve) and neutral (-ve) wires from the Power Supply Unit
(PSU) to the DC POWER INPUT port. Ensure the polarity of the connection is
made correctly.
12. Check all jumpers. For more information, see Section 7.6: Jumper settings.
13. Check all connections thoroughly, including the polarity of each connection.
Once you have verified all connections power can be applied to the ADE5300.
