Siemens ADE5300

Technical specifications
6
Siemens AB
Security Products 05.2015
3 Technical specifications
Electrical
Power (input)
12 V DC, -15 to +10% or
24 V DC, -15 to +10%
Consumption max. 2 A @ 12 V, max. 1.5 A @ 24 V
(max Consumption: All Relays are driven and all open
collector outputs are supplying the max. current of 100 mA.
The reader power supplies are not included!)
Communications FLN RS-485 two wire, half-duplex
Reader Interfaces 8 x Wiegand Reader Interfaces, or
1 x Siemens RS-485 Reader Interface for
connecting up to eight Readers
Lock output 8 x Relay driven 2 A @ 30 V DC
Auxiliary output 8 x Open-Collector 100 mA @ 9.7 – 12 V DC
Inputs (internally supplied) 8 x Door contact
8 x Request-to-Exit
16 x Auxiliary
All inputs unsupervised or supervised
Supervision Requires connection of a supervision circuit.
Fire Override (FOR) input 2 x Normal or Enhanced Modes:
 Normal Mode requires an Input Voltage of
12 V DC
 Enhanced mode requires the connection of
22 kOhm resistor circuits. Cable must be shielded
and total cable run resistance must not exceed
100 Ohms.
Fire Override (FOR) output 2 x Relay 2 A @ 30 V DC
Local input 1 x passive device connection (unsupervised)
Local output 1 x open-collector 100 mA @ 9.7– 12 V DC
Reader Power supplies 8 x 400 mA @ 9.7 – 12 V DC
1 x 1.5 A @ 9.7 – 12 V DC
Dimensions
with baseplate (W x H x D) 250 x 287 x 50 mm (9.84 x 11.30 x 1.97")
without baseplate (W x H x D) 216 x 267 x 37 mm (8.50 x 10.51 x 1.46“)
Environmental
Operating temperature 0 – 50 °C (32 – 122 °F)
Storage temperature 0 – 60 °C (32 – 140 °F )
Humidity 10 – 90% (non-condensing)
Standards and Guidelines
European Directives
“Directive of Electromagnetic
Compatibility”
Emitted interference: EN 61000-6-3: 2001
EN 55022 +A1 +A2 Kl. B: 2003
Interference resistance: EN 50130-4 +A2: 2003
C-Tick Standard for Australia and New Zealand (equivalent
to EN 55022 of the European Directive).
UL-Directives UL 294 Access control units
Details can be found under: http://database.ul.com/cgi-
bin/XYV/template/LISEXT/1FRAME/gfilenbr.html with UL File
Number: BP9490
