Standard I/O Modules
SICAM A8000 Series, SICAM I/O Modules Unrestricted 45
DC8-012-2.06, Edition 09.2019
2.6 AI-8310
2.6.1 Features
Analog input module
• Mounting on DIN rail
• 4 inputs (2 groups of 2 each)
• Galvanic insulation by optocouplers
• Acquisition of temperatures via Pt100/Pt1000/Ni100 resistance measurement in 2-wire-,
3-wire- and 4-wire-technique
• Noise rejection
• Removable screw terminals
• Function indication via LED
2.6.2 View
