ARCADIS Avantic SPR2-330.662.01 Page 2 of 2 Siemens AG
Rev. 02 05.06 CS PS SP Medical Solutions
6 - 2 Technical Data
Maximum deviations 6
Fluoroscopy
Basic measurement used
Tube Housing Assemblies 6
Cooling curves
Definitions of the measurement bases of technique factors 6
Peak tube potential: 6
Measurement of kVp at radiography and at fluoroscopy, using PTW-Nomex (2 filter
method).
Tube current: 6
As measured in the mA-measuring pins D1.X39-D1.X40 (x97 opened) in the tube current
circuit near ground with an mA-meter (FLUKE 8060 A or equivalent), minus the current
flowing through the built-in high-voltage divider of 0.0025 mA/kV
p
.
Tube voltage: ± 10 %
Tube current: ± 10 % ± 0.1 mA
Scene timer: 0 to 5 min. tolerance 1 digit (6 sec)
(Tested IEC601/ 2 / 7)
Peak tube potential: DIADOS (2 filter method)
Tube current: by using RMS-multimeter
Maximum rated peak tube potential: 125 kV
p
Leakage technique factors: 125 kV
p
/4.3 mA/550 W
125 kV
p
/7.8 mA/1000 W
Minimum filtration permanently in the useful beam:
obtained at:
>
3,1 mm Al equivalent
80 kV
p
Minimum filtration permanently in the useful beam:
obtained at:
> 4,5 mm AL equivalent
125 kV
p
Tube housing cooling curve: See Operator‘s Manual
Tube rating charts: See Operator‘s Manual
