Siemens ARCADIS Varic Installation And Startup Guide

Siemens AG SPR2-310.814.05.02.02 ARCADIS
01.05 CS SD 24
Prerequisites 5
Page 5 of 12
Medical Solutions
Fig. 1: Kit
Pos. 1 Threaded plate
Pos. 2 Mounting frame
Pos. 3 Video splitter
Pos. 4 Line and VGA cables
Pos. 5 Slider
Tools 0
Tool kit
Safety information 0
WARNING
Risk of physical injury or death and property damage!
Noncompliance can lead to death, physical injury or property
damage.
Strictly follow:
¹ The product-specific safety information in these instruc-
tions
¹ The general safety information in the instructions
TD00-000.860.01... and
¹ The general safety information according to ARTD part 2.

Siemens ARCADIS Varic Specifications

General

Type	Mobile C-arm
Image Intensifier	9-inch or 12-inch
DICOM Compatibility	Yes
Frame Rate	Up to 30 fps
Focal Spot Size	0.3/0.6 mm
Monitor	Dual 18-inch TFT LCD monitors
