6 Installation and settings
ARCADIS SPR2-310.814.05.02.02 Siemens AG
01.05 CS SD 24
Page 6 of 12
Medical Solutions
2- 2Installation and settings
Work sequence 0
Installation of the video splitter 0
NOTE
These instructions describe installation of the option for the "live"
and the "reference" monitor.
If only the "live" option is available, carry out the cabling and the
mechanical installation for the "live" monitor.
Fig. 2: Cables
