Siemens Argus 7SR22 Installation Guide

7SR21 & 7SR22 Argus Installation Guide
7.3 Typical Connection: 7SR22 Directional OC/EF and NVD
S1
S2
P1
P2
L1 L2 L3
V
L
V
N
NOTES
1) CT circuits are shown connected to 1A tap – use alternative tap for 5A rated CTs.
2) CT and Earth connections are typical only.
3) Application shows use of V
4
as an NVD input.
4) Star Connected VT: Phase Voltage Config:-V
an
,V
bn
,V
cn
I
L1
(I
A
)
1
2
5
6
9
10
13
14
A
17
18
19
20
21
22
23
24
25
26
27
28
1A
5A
1A
5A
1A
5A
1A
5A
15
16
11
12
1A
5A
3
4
7
8
B
C
V
4
(V
X
)
V
L3
(V
C
)
V
L2
(V
B
)
V
L1
(V
A
)
I
L2
(I
B
)
I
L3
(I
C
)
I
4
(I
G
)
I
5
(I
SEF
)
Figure 7.3-1 7SR22 Applied to Feeder Including NVD Protection
©2010 Siemens Protection Devices Limited Chapter 5 Page 19 of 22

Siemens Argus 7SR22 Specifications

General

Type	Feeder Protection Relay
Frequency	50/60 Hz
Binary Outputs	Up to 8
Current Inputs	1 A or 5 A
Communication	Ethernet, RS485
Protocols	Modbus, DNP3
Protection Functions	Overcurrent, Earth Fault, Thermal Overload
Operating Temperature	-25 to +70 °C
Humidity	5 to 95% non-condensing
