12 List of available level 3 (basic)spare parts
(according to Component Matrix V1.09 - check C-market for updates)
Product ID Order Number Description CM
AX72 C1605 L36853-C6224-M6 CAPACITOR 2220N (Cap-Type3)
AX72 R1614 L50652-C472-J2 RESISTOR 4K7 (Res-Type11)
AX72 V286 L36840-L2056-D670 LED AMBER
AX72 V287 L36840-L2056-D670 LED AMBER
AX72 V288 L36840-L2056-D670 LED AMBER
AX72 V289 L36840-L2056-D670 LED AMBER
AX72 V290 L36840-L2056-D670 LED AMBER
AX72 V291 L36840-L2056-D670 LED AMBER
AX72 X1400 L36334-Z97-C213 CONNECTOR BATTERY 3-POL
AX72 X1603 L36334-Z97-C337 CONNECTOR SIM CARD READER K1
AX72 X211 L36334-Z93-C303 IO-JACK SLIM 12-POL
AX72 X2202 L36334-Z97-C205 CONNECTOR DISPLAY 10POL
13 Hardware requirements
(according to General soldering information V1.3 - check C-market for updates)
Jigs, Tools and working materials for all described repairs:
hot air blower
soldering gun
tweezers
flux
solder
