Release 1.1
Technical Documentation
01/2006
TD_Repair_L1-L3_AX72_R1.1.pdf Page 5 of 41
2 AX72 Interface to Accessories
There are no specific mechanical interfaces to the car cradle. The car cradle is designed to
fit the existing design. The I/O-Connector (Lumberg-slim-connector) is in use. The
compatible interface is suitable to use the travel charger.
3 Unit Description of AX72
The AX72 is designed as a Mono Block with non-exchangeable housing. The Upper case,
lower case and battery cover are painted parts. IMD Lens will be mounted by Ultrasonic,
Display, 130X130; semi-bridgeless keypad, 4-way Navi-Key, 12 keys block; IMD lens; IRDA
window; No ID concept will be realized on Battery cover.
Company Confidential
2006©BenQ
