Siemens C45 User Manual

V1.0 Page 4 of 46 ICM MP CCQ ST
C45, M50 AND MT50 Company Confidential © Copyright Siemens AG 05/02
1 List of available level 2,5e parts
C45, M50 + MT50
ID-No Type Name, Location Part-No.
D100 IC Egold+ L36810-G6132-D670
D361 IC ASIC L36145-J4682-Y29
D800 IC Transceiver IC L36820-L6081-D670
D920 IC PA_Comperator L36820-L6084-D670
N386 IC
Volt.Regulator_ZUB
L36820-C6161-D670
N840 IC
Volt.Regulator_RF
L36810-C6065-D670
R959 Resistor Temp_Resistor L36120-F4223-H
L366 Diode Diode_AF L36840-D3084-D670
V342
Transistor Tran._Charge L36830-C1104-D670
V344
Diode Diode_Charge L36840-D5061-D670
V442
Transistor Tran._SW_Vibra L36830-C1097-D670
V850
Transistor Tran._VCO_Switch L36820-C6047-D670
V880
Transistor Tran._Sw_Diplexer L36820-C6047-D670
V881
Transistor Tran._Sw_Diplexer L36820-C6047-D670
V920
Diode Feedback_Diode L36840-D5049-D670
V922
Transistor Tran._PA_Control L36840-C4009-D670
V950
Transistor Tran._26MHz_Ampl. L36840-C4049-D670
V951
Diode Capa_Diode L36840-D61-D670
Z100 Quartz Quarz/Egold L36145-F102-Y8
Z850
VCO
1LO_VCO L36145-G100-Y93
Z851 Filter Filter_BALUN L36145-K260-Y31
Z880 IC Ant_Switch_Diplexer L36145-K280-Y181
Z890
VCO
Transmitter_VCO L36145-G100-Y92
Z900 IC Power_Amplifier L36851-Z2002-A45
Z950 Quartz Oszillator_26MHz L36145-F260-Y16
