Company Confidential
Copyright 2003© Siemens AG
Page 4 of 13
Service Repair Documentation
Level 2.5 - C65
Release 1.0
1 C65 board layout
Jigs, Tools and Working materials for all described repairs:
- hot air blower
- soldering gun
- tweezers
- flux
- solder
Joystick SW
Diode
IRDA
Connector
SIM CARD READER
Connector
IO JACK
Connector
BOARD TO BOARD
Connector
BATTERY
Connector
RF
Connector
Board to Board
Connector
Display
