Siemens C65 Service Repair Documentation

Company Confidential
Copyright 2003© Siemens AG
Page 7 of 13
Service Repair Documentation
Level 2.5 - C65
Release 1.0
4 Connector Board to Board
Fault Symptoms
Customer: GRT:
Keyboard malfunction Keyboard malfunction
Keypad illumination does not work Tbd.
Connector Board to Board
Use hot air blower to remove defective component. Avoid excessive heat! Watch surrounding components!
Resolder new component afterwards.
E-commerce order number: L36334-Z97-C162
Soldering temperature: 240 - 255°C
IRIS Diagnose Code: 32100 Keys / Main / No Function
32200 Keys / Main / Reduced Functionality
36000 Keys / Illumination
B to B connector Problems
Check the status of the
BtoB connector visually
okay
not okay
Level 2 Repair
Exchange
BtoB connector
- check for twisted or
bended contacts
- check for dry joints
not okay
okay
Watch for oxidation and
damaged pads of the BtoB
connector
SCRAP don´t
send back to
WSC
