The LED in orange light indicates good network connection.
8.3 Connect Alarm I/O
The camera equips one alarm input and one relay output for alarm application. Re-
fer to alarm pin definition below to connect alarm devices to the IP Camera if
needed.
PIN 1: Output +
PIN 2: Output −
PIN 3: Input +
PIN 4: Input −
