e1453b
13
Fire & Security Products
Siemens Building Technologies Group
12.2001
2 Installation
2.1 General
2.1.1 Responsibility
The planning engineer is responsible for the correct installation of the fire detection sys-
tem. He is responsible for positioning equipment correctly and preparing the necessary
documentation.
The electrician is responsible for the line network and the wiring up of the equipment as
well as the permanent mounting of devices.
2.1.2 Storage of equipment on site
The installer is responsible for the storage and safety of equipment.
Store equipment in a dry, clean room.
Leave equipment in its original packing until required for use.
Only insert fire detectors, control unit modules etc. when commissioning the system.
2.1.3 Installation documentation
The following installation documentation must be provided by the planner for correct
installation:
Ground plans with equipment locations drawn in and/or
Lists of equipment indicating the location of equipment
Block diagrams with the architecture of the supply network.
Connection diagram for equipment, intermediate distribution frame, control unit and
terminal
Information on the use of special cables, explosion-hazard applications etc.
2.1.4 Marking of equipment
If required, two different designation plates are available for the marking of detectors.
They are attached under the detector base after installation.
As component parts of a fire detection system, terminal boxes, distributor boxes, loop-
ing-in boxes must be marked accordingly.
