1.2 Basic wiring layout of a fire detection system
Extra-low voltage 16...30VDC Low voltage 110...240VAC
Alarm device line
Line to
control and
indication terminal
Door magnet line
Control unit
CC/CI..
Line to
remote transmission system
for alarms and faults
Detection line
Fire control installation
Mains supply
110...240VAC
Fuse
~
~
CT..
Door magnet
line
CC/CI...
FDC
Fig. 3 Basic fire detection system layout
