PXL Conventional Fire Alarm Control Panel
Installation
6
4. Install any optional PRM-4 relay modules.
5. Install any optional PNC-2Z Notification Appliance Circuit
modules.
6. Install power/data interconnect cable between modules on lower
level of bracket as well as the power/data interconnect cable for
the modules on the upper level of the mounting bracket.
7. Install the PCM-1 Main Control module.
8. Plug in the power/data interconnect cable from the PPS-10M
board and from PCM-1.
9. Install any optional PZE-4B zone expander modules.
Install interconnecting cables.
10. Install the PMK-1 module bracket in the PSE-1 enclosure.
11. Install the PTX-12 transformer.
12. Install the grounding straps
13. Check field wiring.
14. Install field wiring (including the main power connections). Refer
to the PXL Connection Diagram at the end of the manual.
15. Install all system labels.
16. Install the door to the backbox.
17. Power-up the PXL.
