Siemens Connect X200 User Manual

6
Siemens
A6V11974867_en--_b
Smart Infrastructure
2021-08-30
Screw terminals for wire cross sections up to
Max. 2.5 mm
2
(14 AWG)
Internal fusing
2.5 A irreversible / non-replaceable
External supply line fusing (EU)
Non-renewable fuse max. 10 A slow
or
circuit breaker max. 13 A
Tripping characteristic B, C, D per EN 60898
or
Power supply with current limitation of max. 10 A
Power consumption (for transformer planning)
Power consumption AC
16 VA
Power consumption DC
8 W
Function data
Hardware information
Processor
NXP i.MX8 DualX
Storage
2 GB RAM
8 GB eMMC
Data backup in the event of power failure
Super cap to support real-time clock (7 days).
Interfaces
Ethernet interfaces
Plug
3 x RJ45, shielded
Interface type
10Base-T / 100Base-TX, IEEE 802.3 compatible
Bit rate
10/100 Mbps, autosensing
Protocol
BACnet on UDP/IP and HTTPs on TCP/IP
Cabling, cable type
10 Mbps: Min. CAT3, shielded cable is recommended
100 Mbps: Min. CAT5, shielded cable is recommended
Cable length
Max. 100 m (330 ft)
Screw terminals, plug-in
Cu-wire or Cu-strand with wire end sleeve
1 x 0.6 mm ∅ to 2.5 mm
2
(22 to 14 AWG)
or 2 x 0.6 mm ∅ to 1.0 mm
2
(22 to 18 AWG)
Cu-strand without wire end sleeve
1 x 0.6 mm ∅ to 2.5 mm
2
(22 to 14 AWG)
or 2 x 0.6 mm ∅ to 1.5 mm
2
(22 to 16 AWG)
Stripping length
6...7.5 mm (0.24...0.29 in)
Screwdriver
Slot screws, screwdriver size 1 with shaft ø = 3 mm
Max. tightening torque
0.6 Nm (0.44 lb ft)
