&RPPLVVLRQLQJ
S7-300 Automation System, Hardware and Installation: CPU 31xC and CPU 31x
A5E00105492-03
9-31
:RUNLQJZLWKLQWHUPHGLDWHPHPRU\
Note the following rules when working with intermediate memory:
• Assignment of address areas:
– Input data of DP slaves are DOZD\V output data of the DP master
– Output data of DP slaves are DOZD\V input data of the DP master
• The user can define these addresses. In the user program, access data with
load/transfer instructions or with SFC 14 and SFC 15. You can also specify
addresses from the input/output process image (refer to Chapter $GGUHVVLQJ
8VHUGHILQHG$GGUHVVLQJRI0RGXOHV).
• The lowest address of specific address areas is their respective area start
address.
• The length, unit and consistency of the address areas for DP master and DP
slave must be identical.
1RWH
Assign addresses from the DP address area of the DP
memory.
ou must not assi
n addresses specified for the intermediate memor
a
ain for
the I/O modules on the DP CPU. When using consistent data areas in
intermediate memory, note the section on &RQVLVWHQW'DWD in Chapter
$GGUHVVLQJ.
6'3PDVWHU
If you use an IM 308-C as a DP master and the DP CPU as a DP slave, the
following applies to the exchange of consistent data.
You must program FB192 in IM 308-C to enable exchange of consistent data
between a DP master and the DP slave. With the FB192, the data of the DP CPU
are only output or read out in a consistent block.
6DV'3PDVWHU
If you set up an AG S5-95 as a DP master, you must also set its bus parameters
for the DP CPU as a DP slave.
'DWDWUDQVIHULQ6723PRGH
The DP slave CPU goes into STOP mode: Data in CPU intermediate memory are
overwritten with "0". That is, the DP master reads "0".
The DP master goes into STOP mode: Actual data in CPU intermediate memory is
maintained and can still be read by the CPU.
352),%86DGGUHVV
For the DP CPU, you must QRWset as a PROFIBUS address.
