Siemens CPU 315-2 DP User Manual

CPU 31xC and CPU 31x, Technical Data
Manual, 01/2006 Edition, A5E00105475-06
iii
Preface
Purpose of the Manual
This manual contains all the information you will need concerning the configuration,
communication, memory concept, cycle, response times and technical data for the CPUs.
You will then learn the points to consider when upgrading to one of the CPUs discussed in
this manual.
Required basic knowledge
• To understand this manual, you require a general knowledge of automation engineering.
• You should also be accustomed to working with STEP 7 basic software.
Area of application
Table 1 Application area covered by this manual
as of version
CPU Convention:
CPU designations:
Order number
Firmware Hardware
CPU 312C 6ES7312-5BD01-0AB0 V2.0.0 01
CPU 313C 6ES7313-5BE01-0AB0 V2.0.0 01
CPU 313C-2 PtP 6ES7313-6BE01-0AB0 V2.0.0 01
CPU 313C-2 DP 6ES7313-6CE01-0AB0 V2.0.0 01
CPU 314C-2 PtP 6ES7314-6BF02-0AB0 V2.0.0 01
CPU 314C-2 DP
CPU 31xC
6ES7314-6CF02-0AB0 V2.0.0 01
CPU 312 6ES7312-1AD10-0AB0 V2.0.0 01
CPU 314 6ES7314-1AF11-0AB0 V2.0.0 01
CPU 315-2 DP 6ES7315-2AG10-0AB0 V2.0.0 01
CPU 315-2 PN/DP 6ES7315-2EG10-0AB0 V2.3.0 01
CPU 317-2 DP 6ES7317-2AJ10-0AB0 V2.1.0 01
CPU 317-2 PN/DP 6ES7317-2EJ10-0AB0 V2.3.0 01
CPU 319-3 PN/DP
CPU 31x
6ES7318-3EL00-0AB0 V2.4.0 01

Siemens CPU 315-2 DP Specifications

General

Memory	64 KB
Power Supply	24 V DC
Order Number	6ES7 315-2AG10-0AB0
Number of DP Masters	1
Number of DP Slaves	124
Load Memory	64 KB
Number of Timers	256
Number of Counters	256
Data Memory	64 KB
Operating Temperature	0 to 60 °C
Integrated Interfaces	MPI, DP
Digital Outputs	Not integrated
Analog Inputs	Not integrated
Analog Outputs	Not integrated
Programming Languages	LAD, FBD, STL
Digital Inputs	Not integrated
Weight	660 g
