System Function Blocks
141
S7-400 Instruction List
A5E00267845-01
Execution Time in s
SFC
No.
SFC Name Function
CPU
412
CPU
414
CPU
416
CPU
417
CPUs
414-4H
417-4H
(solo)
CPUs
414-4H
417-4H
(redun-
dant)
14 GET Read data from remote CPU
(one area specified)
JOB activated
335 186 129 113 xx xx
JOB checked 149 86 57 49 xx xx
JOB finished (NDR = 1; 1 - 450 bytes) 282 -
316
163 -
183
108 -
121
92 - 106 xx - xx xx - xx
15 PUT Write data to remote CPU
JOB activated (1 - 404 bytes)
445 -
478
257 -
277
173 -
180
147 -
160
xx - xx xx - xx
JOB checked 149 86 57 49 xx xx
JOB finished (DONE = 1) 147 85 56 48 xx xx
16 PRINT Send data to a printer
JOB activated, REQ = 1
462 -
502
260 -
284
174 -
186
150 -
162
xx - xx xx - xx
JOB checked 153 88 58 50 xx xx
JOB finished, DONE = 1 152 86 57 49 xx xx
