System Function Blocks
142
S7-400 Instruction List
A5E00267845-01
Execution Time in s
SFC
No.
SFC Name Function
CPU
412
CPU
414
CPU
416
CPU
417
CPUs
414-4H
417-4H
(solo)
CPUs
414-4H
417-4H
(redun-
dant)
19 START Start remote device
JOB activated, REQ = 1
443 251 164 147 xx xx
JOB checked 155 90 60 52 xx xx
JOB finished, DONE = 1 153 89 59 51 xx xx
20 STOP Stop remote device
JOB activated, REQ = 1
411 242 157 136 xx xx
JOB checked 156 90 59 51 xx xx
JOB finished, DONE = 1 153 89 58 51 xx xx
21 RESUME Restart remote device
JOB activated, REQ = 1
434 246 159 142 xx xx
JOB checked 157 90 59 52 xx xx
JOB finished, DONE = 1 153 90 59 52 xx xx
22 STATUS Query status of remote partner
JOB activated, REQ = 1
279 160 109 97 xx xx
JOB checked 153 88 58 50 xx xx
JOB finished, NDR = 1 464 269 177 151 xx xx
